Technical Specifications of J109_D75Z
| Datasheet |  J109_D75Z datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - JFETs |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Box (TB) |
|---|
| FET Type | N-Channel |
|---|
| Voltage - Breakdown (V(BR)GSS) | 25V |
|---|
| Drain to Source Voltage (Vdss) | - |
|---|
| Current - Drain (Idss) @ Vds (Vgs=0) | 40mA @ 15V |
|---|
| Current Drain (Id) - Max | - |
|---|
| Voltage - Cutoff (VGS off) @ Id | 2V @ 10nA |
|---|
| Input Capacitance (Ciss) @ Vds | - |
|---|
| Resistance - RDS(On) | 12 Ohm |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) (Formed Leads) |
|---|
| Supplier Device Package | TO-92-3 |
|---|
| Power - Max | 625mW |
|---|
We can supply Fairchild Semiconductor part# J109_D75Z. Use the request quote form to request J109_D75Z pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number J109_D75Z. The price and lead time for J109_D75Z depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# J109_D75Z. We look forward to doing business with you.
