Technical Specifications of HM78D-128390MLFTR
| Datasheet |  HM78D-128390MLFTR datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | TT Electronics/BI Magnetics |
|---|
| Series | HM78D |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 156μH |
|---|
| Inductance - Connected In Parallel | 39μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating - Parallel | 3.6A |
|---|
| Current Rating - Series | 1.6A |
|---|
| Current Saturation - Parallel | 5.5A |
|---|
| Current Saturation - Series | 2.8A |
|---|
| DC Resistance (DCR) - Parallel | 80 mOhm |
|---|
| DC Resistance (DCR) - Series | 320 mOhm |
|---|
| Shielding | Shielded |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
|---|
| Height | 0.317" (8.05mm) |
|---|
We can supply TT Electronics/BI Magnetics part# HM78D-128390MLFTR. Use the request quote form to request HM78D-128390MLFTR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number HM78D-128390MLFTR. The price and lead time for HM78D-128390MLFTR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# HM78D-128390MLFTR. We look forward to doing business with you.
