Technical Specifications of CI100505-2N2D
| Datasheet |  CI100505-2N2D datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Bourns Inc. |
|---|
| Series | CI100505 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Multilayer |
|---|
| Material - Core | Ceramic |
|---|
| Inductance | 2.2nH |
|---|
| Tolerance | ±0.3nH |
|---|
| Current Rating | 300mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 130 mOhm Max |
|---|
| Q @ Freq | 8 @ 100MHz |
|---|
| Frequency - Self Resonant | 6GHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Frequency - Test | 100MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 0402 (1005 Metric) |
|---|
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
|---|
| Height - Seated (Max) | 0.022" (0.55mm) |
|---|
We can supply Bourns Inc. part# CI100505-2N2D. Use the request quote form to request CI100505-2N2D pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CI100505-2N2D. The price and lead time for CI100505-2N2D depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CI100505-2N2D. We look forward to doing business with you.
