DAC7551TDRNRQ1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DAC7551TDRNRQ1 |
|---|---|
| Manufacturer | Texas Instruments |
| Description | 12 Bit Digital to Analog Converter 1 12-USON (3x2) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DAC7551TDRNRQ1 Price |  |
Technical Specifications of DAC7551TDRNRQ1
| Datasheet |  DAC7551TDRNRQ1 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Texas Instruments |
| Series | Automotive, AEC-Q100 |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Number of Bits | 12 |
| Number of D/A Converters | 1 |
| Settling Time | 5μs |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | SPI, DSP |
| Reference Type | External |
| Voltage - Supply, Analog | 2.7 V ~ 5.5 V |
| Voltage - Supply, Digital | 2.7 V ~ 5.5 V |
| INL/DNL (LSB) | ±0.35, ±0.08 |
| Architecture | String DAC |
| Operating Temperature | -40°C ~ 105°C |
| Package / Case | 12-UFDFN Exposed Pad |
| Supplier Device Package | 12-USON (3x2) |
