TSC2200IRHB
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TSC2200IRHB |
|---|---|
| Manufacturer | Texas Instruments |
| Description | Touchscreen Controller 4-Wire 12 bit SPI Interface 32-VQFN (5x5) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TSC2200IRHB Price |  |
Technical Specifications of TSC2200IRHB
| Datasheet |  TSC2200IRHB datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Touch Screen Controllers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Type | Resistive, Driver |
| Touch Panel Interface | 4-Wire |
| Number of Inputs/Keys | 1, 4 x 4 Keypad |
| Resolution (Bits) | 12 b |
| Evaluation Tools | Available |
| Data Interface | SPI |
| Data Rate/Sampling Rate (SPS, BPS) | 125k |
| Voltage Reference | External, Internal |
| Voltage - Supply | 2.7 V ~ 3.6 V |
| Current - Supply | 1.25mA |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 32-VFQFN Exposed Pad |
| Supplier Device Package | 32-VQFN (5x5) |
