EPM7160EQC100-12
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | EPM7160EQC100-12 |
|---|---|
| Manufacturer | Altera |
| Description | IC CPLD 160MC 12NS 100QFP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| EPM7160EQC100-12 Price |  |
Technical Specifications of EPM7160EQC100-12
| Datasheet |  EPM7160EQC100-12 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Embedded - CPLDs (Complex Programmable Logic Devices) |
| Manufacturer | Altera |
| Series | MAX? 7000 |
| Packaging | Tray |
| Part Status | Active |
| Programmable Type | EE PLD |
| Delay Time tpd(1) Max | 12.0ns |
| Voltage Supply - Internal | 4.75 V ~ 5.25 V |
| Number of Logic Elements/Blocks | 10 |
| Number of Macrocells | 160 |
| Number of Gates | 3200 |
| Number of I/O | 84 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 100-BQFP |
| Supplier Device Package | 100-PQFP (14x20) |
