GAL20V8C-7LJN
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | GAL20V8C-7LJN |
|---|---|
| Manufacturer | Lattice Semiconductor Corporation |
| Description | IC CPLD 8MC 7.5NS 28PLCC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| GAL20V8C-7LJN Price |  |
Technical Specifications of GAL20V8C-7LJN
| Datasheet |  GAL20V8C-7LJN datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Embedded - CPLDs (Complex Programmable Logic Devices) |
| Manufacturer | Lattice Semiconductor Corporation |
| Series | GAL?20V8 |
| Packaging | Tube |
| Part Status | Obsolete |
| Programmable Type | EE PLD |
| Delay Time tpd(1) Max | 7.5ns |
| Voltage Supply - Internal | 4.75 V ~ 5.25 V |
| Number of Logic Elements/Blocks | - |
| Number of Macrocells | 8 |
| Number of Gates | - |
| Number of I/O | - |
| Operating Temperature | 0°C ~ 75°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 28-LCC (J-Lead) |
| Supplier Device Package | 28-PLCC (11.51x11.51) |
