ATF1502AS-15AC44
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ATF1502AS-15AC44 |
|---|---|
| Manufacturer | Atmel |
| Description | IC CPLD 32MC 15NS 44TQFP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| ATF1502AS-15AC44 Price |  |
Technical Specifications of ATF1502AS-15AC44
| Category | Integrated Circuits (ICs) |
|---|---|
| Family | Embedded - CPLDs (Complex Programmable Logic Devices) |
| Manufacturer | Atmel |
| Series | ATF15xx |
| Packaging | Tray |
| Part Status | Obsolete |
| Programmable Type | In System Programmable (min 10K program/erase cycles) |
| Delay Time tpd(1) Max | 15.0ns |
| Voltage Supply - Internal | 4.75 V ~ 5.25 V |
| Number of Logic Elements/Blocks | - |
| Number of Macrocells | 32 |
| Number of Gates | - |
| Number of I/O | 32 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 44-TQFP |
| Supplier Device Package | 44-TQFP (10x10) |
