AT94S05AL-25DGC
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AT94S05AL-25DGC |
|---|---|
| Manufacturer | Atmel |
| Description | IC FPSLIC 5K GATE 25MHZ 256BGA |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| AT94S05AL-25DGC Price |  |
Technical Specifications of AT94S05AL-25DGC
| Category | Integrated Circuits (ICs) |
|---|---|
| Family | Embedded - FPGAs (Field Programmable Gate Array) with Microcontrollers |
| Manufacturer | Atmel |
| Series | FPSLIC? |
| Packaging | Tray |
| Part Status | Obsolete |
| Core Type | 8-bit AVR |
| Speed | 25MHz |
| Interface | I2C, UART |
| Program SRAM Bytes | 4K-16K |
| FPGA SRAM | 2kb |
| EEPROM Size | 256K x 8 |
| Data SRAM Bytes | 4K ~ 16K |
| FPGA Core Cells | 256 |
| FPGA Gates | 5K |
| FPGA Registers | 436 |
| Voltage - Supply | 3 V ~ 3.6 V |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 256-LBGA, CABGA |
| Supplier Device Package | 256-CABGA (17x17) |
