Technical Specifications of MC9S12XDT512MAG
| Datasheet |  MC9S12XDT512MAG datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | Embedded - Microcontrollers |
|---|
| Manufacturer | Freescale Semiconductor - NXP |
|---|
| Series | HCS12X |
|---|
| Packaging | Tray |
|---|
| Part Status | Active |
|---|
| Core Processor | HCS12X |
|---|
| Core Size | 16-Bit |
|---|
| Speed | 80MHz |
|---|
| Connectivity | CAN, EBI/EMI, I2C, IrDA, LIN, SCI, SPI |
|---|
| Peripherals | LVD, POR, PWM, WDT |
|---|
| Number of I/O | 119 |
|---|
| Program Memory Size | 512KB (512K x 8) |
|---|
| Program Memory Type | FLASH |
|---|
| EEPROM Size | 4K x 8 |
|---|
| RAM Size | 20K x 8 |
|---|
| Voltage - Supply (Vcc/Vdd) | 2.35 V ~ 5.5 V |
|---|
| Data Converters | A/D 24x10b |
|---|
| Oscillator Type | External |
|---|
| Operating Temperature | -40°C ~ 125°C (TA) |
|---|
| Package / Case | 144-LQFP |
|---|
| Supplier Device Package | 144-LQFP (20x20) |
|---|
We can supply Freescale Semiconductor - NXP part# MC9S12XDT512MAG. Use the request quote form to request MC9S12XDT512MAG pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MC9S12XDT512MAG. The price and lead time for MC9S12XDT512MAG depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MC9S12XDT512MAG. We look forward to doing business with you.
