DG534ADJ-E3
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DG534ADJ-E3 |
|---|---|
| Manufacturer | Vishay Siliconix |
| Description | IC AMP/VIDEO/MUX LP 4/8CH 20DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DG534ADJ-E3 Price |  |
Technical Specifications of DG534ADJ-E3
| Datasheet |  DG534ADJ-E3 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches - Special Purpose |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Applications | Ultrasound, Video |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Switch Circuit | SPDT |
| Number of Channels | 2 |
| On-State Resistance (Max) | 90 Ohm |
| Voltage - Supply, Single (V+) | 10 V ~ 21 V |
| Voltage - Supply, Dual (V±) | - |
| -3db Bandwidth | 500MHz |
| Features | T-Switch Configuration |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 20-DIP (0.300", 7.62mm) |
| Supplier Device Package | 20-PDIP |
