74LVC1284D,112
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 74LVC1284D,112 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | 4/4 Transceiver Full IEEE 1284 20-SO |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 74LVC1284D,112 Price |  |
Technical Specifications of 74LVC1284D,112
| Category | Integrated Circuits (ICs) |
|---|---|
| Family | Interface - Drivers, Receivers, Transceivers |
| Manufacturer | NXP Semiconductors |
| Series | 74LVC |
| Packaging | Tube |
| Part Status | Obsolete |
| Type | Transceiver |
| Protocol | IEEE 1284 |
| Number of Drivers/Receivers | 4/4 |
| Duplex | Full |
| Receiver Hysteresis | 400mV |
| Data Rate | - |
| Voltage - Supply | 3 V ~ 3.6 V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SO |
