MC74LCX245DWR2G
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MC74LCX245DWR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | Transceiver, Non-Inverting 1 Element 8 Bit per Element Push-Pull Output 20-SOIC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MC74LCX245DWR2G Price |  |
Technical Specifications of MC74LCX245DWR2G
| Datasheet |  MC74LCX245DWR2G datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Buffers, Drivers, Receivers, Transceivers |
| Manufacturer | ON Semiconductor |
| Series | 74LCX |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Logic Type | Transceiver, Non-Inverting |
| Number of Elements | 1 |
| Number of Bits per Element | 8 |
| Input Type | - |
| Output Type | Push-Pull |
| Current - Output High, Low | 24mA, 24mA |
| Voltage - Supply | 2 V ~ 5.5 V |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SOIC |
