SN74S51N
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SN74S51N |
|---|---|
| Manufacturer | Texas Instruments |
| Description | AND/OR/INVERT Gate Configurable 2 Circuit 8 Input (2, 2, 2, 2) Input 14-PDIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SN74S51N Price |  |
Technical Specifications of SN74S51N
| Datasheet |  SN74S51N datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Gates and Inverters - Multi-Function, Configurable |
| Manufacturer | Texas Instruments |
| Series | 74S |
| Packaging | Tube |
| Part Status | Active |
| Logic Type | AND/OR/INVERT Gate |
| Number of Circuits | 2 |
| Number of Inputs | 8 Input (2, 2, 2, 2) |
| Schmitt Trigger Input | No |
| Output Type | Single-Ended |
| Current - Output High, Low | 1mA, 20mA |
| Voltage - Supply | 4.75 V ~ 5.25 V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Package / Case | 14-DIP (0.300", 7.62mm) |
| Supplier Device Package | 14-PDIP |
