SY10E107JZ
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SY10E107JZ |
|---|---|
| Manufacturer | Microchip Technology |
| Description | XOR/XNOR Gate Configurable 5 Circuit 10 Input (2, 2, 2, 2, 2) Input 28-PLCC (11.5x11.5) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SY10E107JZ Price |  |
Technical Specifications of SY10E107JZ
| Datasheet |  SY10E107JZ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Gates and Inverters - Multi-Function, Configurable |
| Manufacturer | Microchip Technology |
| Series | 10E |
| Packaging | Tube |
| Part Status | Obsolete |
| Logic Type | XOR/XNOR Gate |
| Number of Circuits | 5 |
| Number of Inputs | 10 Input (2, 2, 2, 2, 2) |
| Schmitt Trigger Input | No |
| Output Type | Differential |
| Current - Output High, Low | - |
| Voltage - Supply | 4.2 V ~ 5.5 V |
| Operating Temperature | 0°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 28-LCC (J-Lead) |
| Supplier Device Package | 28-PLCC (11.5x11.5) |
