MC14572UBCPG
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MC14572UBCPG |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | NAND/NOR Inverter Gate Configurable 6 Circuit 8 Input (1, 1, 2, 2, 1, 1) Input 16-DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MC14572UBCPG Price |  |
Technical Specifications of MC14572UBCPG
| Datasheet |  MC14572UBCPG datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Gates and Inverters - Multi-Function, Configurable |
| Manufacturer | ON Semiconductor |
| Series | 4000B |
| Packaging | Tube |
| Part Status | Obsolete |
| Logic Type | NAND/NOR Inverter Gate |
| Number of Circuits | 6 |
| Number of Inputs | 8 Input (1, 1, 2, 2, 1, 1) |
| Schmitt Trigger Input | No |
| Output Type | Single-Ended |
| Current - Output High, Low | 3.5mA, 8.8mA |
| Voltage - Supply | 3 V ~ 18 V |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Supplier Device Package | 16-DIP |
