Technical Specifications of ISL6614ACBZ-TR5214
| Datasheet |  ISL6614ACBZ-TR5214 datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | PMIC - Gate Drivers |
|---|
| Manufacturer | Intersil |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Obsolete |
|---|
| Driven Configuration | Half-Bridge |
|---|
| Channel Type | Synchronous |
|---|
| Number of Drivers | 4 |
|---|
| Gate Type | N-Channel MOSFET |
|---|
| Voltage - Supply | 10.8 V ~ 13.2 V |
|---|
| Logic Voltage - VIL, VIH | - |
|---|
| Current - Peak Output (Source, Sink) | 1.25A, 2A |
|---|
| Input Type | Non-Inverting |
|---|
| High Side Voltage - Max (Bootstrap) | 36V |
|---|
| Rise / Fall Time (Typ) | 26ns, 18ns |
|---|
| Operating Temperature | 0°C ~ 125°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
|---|
| Supplier Device Package | 14-SOICN |
|---|
We can supply Intersil part# ISL6614ACBZ-TR5214. Use the request quote form to request ISL6614ACBZ-TR5214 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ISL6614ACBZ-TR5214. The price and lead time for ISL6614ACBZ-TR5214 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ISL6614ACBZ-TR5214. We look forward to doing business with you.
