Technical Specifications of MCP14A0154-E/SN
| Datasheet |  MCP14A0154-E/SN datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | PMIC - Gate Drivers |
|---|
| Manufacturer | Microchip Technology |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| Part Status | Active |
|---|
| Driven Configuration | Low-Side |
|---|
| Channel Type | Independent |
|---|
| Number of Drivers | 2 |
|---|
| Gate Type | N-Channel, P-Channel MOSFET |
|---|
| Voltage - Supply | 4.5 V ~ 18 V |
|---|
| Logic Voltage - VIL, VIH | 0.8V, 2V |
|---|
| Current - Peak Output (Source, Sink) | 1.5A, 1.5A |
|---|
| Input Type | Non-Inverting |
|---|
| High Side Voltage - Max (Bootstrap) | - |
|---|
| Rise / Fall Time (Typ) | 11.5ns, 10ns |
|---|
| Operating Temperature | -40°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
|---|
| Supplier Device Package | 8-SOIC |
|---|
We can supply Microchip Technology part# MCP14A0154-E/SN. Use the request quote form to request MCP14A0154-E/SN pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MCP14A0154-E/SN. The price and lead time for MCP14A0154-E/SN depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MCP14A0154-E/SN. We look forward to doing business with you.
