Technical Specifications of ADP3121JRZ-RL
| Datasheet |  ADP3121JRZ-RL datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | PMIC - Gate Drivers |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Obsolete |
|---|
| Driven Configuration | Half-Bridge |
|---|
| Channel Type | Synchronous |
|---|
| Number of Drivers | 2 |
|---|
| Gate Type | N-Channel MOSFET |
|---|
| Voltage - Supply | 4.15 V ~ 13.2 V |
|---|
| Logic Voltage - VIL, VIH | 0.8V, 2V |
|---|
| Current - Peak Output (Source, Sink) | - |
|---|
| Input Type | Non-Inverting |
|---|
| High Side Voltage - Max (Bootstrap) | 35V |
|---|
| Rise / Fall Time (Typ) | 20ns, 20ns |
|---|
| Operating Temperature | 0°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
|---|
| Supplier Device Package | 8-SOIC |
|---|
We can supply ON Semiconductor part# ADP3121JRZ-RL. Use the request quote form to request ADP3121JRZ-RL pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ADP3121JRZ-RL. The price and lead time for ADP3121JRZ-RL depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ADP3121JRZ-RL. We look forward to doing business with you.
