Technical Specifications of A3959SLBTR-T
| Datasheet |  A3959SLBTR-T datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | PMIC - Motor Drivers, Controllers |
|---|
| Manufacturer | Allegro MicroSystems, LLC |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Motor Type - Stepper | - |
|---|
| Motor Type - AC, DC | Brushed DC |
|---|
| Function | Driver - Fully Integrated, Control and Power Stage |
|---|
| Output Configuration | Half Bridge (2) |
|---|
| Interface | Parallel |
|---|
| Technology | DMOS |
|---|
| Step Resolution | - |
|---|
| Applications | General Purpose |
|---|
| Current - Output | 3A |
|---|
| Voltage - Supply | 4.5 V ~ 5.5 V |
|---|
| Voltage - Load | 9.5 V ~ 50 V |
|---|
| Operating Temperature | -20°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 24-SOIC (0.295", 7.50mm Width) |
|---|
| Supplier Device Package | 24-SOIC W |
|---|
We can supply Allegro MicroSystems, LLC part# A3959SLBTR-T. Use the request quote form to request A3959SLBTR-T pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number A3959SLBTR-T. The price and lead time for A3959SLBTR-T depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# A3959SLBTR-T. We look forward to doing business with you.
