Technical Specifications of TMC5130A-TA-T
| Datasheet |  TMC5130A-TA-T datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | PMIC - Motor Drivers, Controllers |
|---|
| Manufacturer | Trinamic Motion Control GmbH |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Motor Type - Stepper | Bipolar |
|---|
| Motor Type - AC, DC | - |
|---|
| Function | Driver - Fully Integrated, Control and Power Stage |
|---|
| Output Configuration | Half Bridge (4) |
|---|
| Interface | SPI, Step/Direction, RS-232 |
|---|
| Technology | Power MOSFET |
|---|
| Step Resolution | 1 ~ 1/256 |
|---|
| Applications | General Purpose |
|---|
| Current - Output | 1.4A |
|---|
| Voltage - Supply | 5.5 V ~ 46 V |
|---|
| Voltage - Load | 4.75 V ~ 46 V |
|---|
| Operating Temperature | -40°C ~ 125°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 48-TQFP Exposed Pad |
|---|
| Supplier Device Package | 48-TQFP-EP (7x7) |
|---|
We can supply Trinamic Motion Control GmbH part# TMC5130A-TA-T. Use the request quote form to request TMC5130A-TA-T pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TMC5130A-TA-T. The price and lead time for TMC5130A-TA-T depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TMC5130A-TA-T. We look forward to doing business with you.
