Technical Specifications of E-L6258E
| Datasheet |  E-L6258E datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | PMIC - Motor Drivers, Controllers |
|---|
| Manufacturer | STMicroelectronics |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| Part Status | Active |
|---|
| Motor Type - Stepper | Bipolar |
|---|
| Motor Type - AC, DC | Brushed DC |
|---|
| Function | Driver - Fully Integrated, Control and Power Stage |
|---|
| Output Configuration | Half Bridge (4) |
|---|
| Interface | Parallel |
|---|
| Technology | DMOS |
|---|
| Step Resolution | 1, 1/2, 1/4, 1/8, 1/16 |
|---|
| Applications | General Purpose |
|---|
| Current - Output | 1.5A |
|---|
| Voltage - Supply | 4.75 V ~ 5.25 V |
|---|
| Voltage - Load | 12 V ~ 40 V |
|---|
| Operating Temperature | 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 36-BSSOP (0.433", 11.00mm Width) Exposed Pad |
|---|
| Supplier Device Package | PowerSO-36 |
|---|
We can supply STMicroelectronics part# E-L6258E. Use the request quote form to request E-L6258E pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number E-L6258E. The price and lead time for E-L6258E depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# E-L6258E. We look forward to doing business with you.
