MAX5095AAUA+T
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX5095AAUA+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | Flyback, Forward Converter Regulator Positive, Isolation Capable Output Step-Up/Step-Down DC-DC Controller IC 8-uMAX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MAX5095AAUA+T Price |  |
Technical Specifications of MAX5095AAUA+T
| Datasheet |  MAX5095AAUA+T datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Output Type | Transistor Driver |
| Function | Step-Up/Step-Down |
| Output Configuration | Positive, Isolation Capable |
| Topology | Flyback, Forward Converter |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 7.6 V ~ 30 V |
| Frequency - Switching | 20kHz ~ 1MHz |
| Duty Cycle (Max) | 96% |
| Synchronous Rectifier | No |
| Clock Sync | Yes |
| Serial Interfaces | - |
| Control Features | Frequency Control |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 8-uMAX |
