10-89-4142
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 10-89-4142 |
|---|---|
| Manufacturer | Molex Connector Corporation |
| Description | 14 Positions Header, Unshrouded, Breakaway Connector 0.100" (2.54mm) Through Hole, Right Angle Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 10-89-4142 Price |  |
Technical Specifications of 10-89-4142
| Datasheet |  10-89-4142 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Molex Connector Corporation |
| Series | C-Grid? 70216 |
| Packaging | Tube |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded, Breakaway |
| Number of Positions | 14 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Contact Mating Length | 0.240" (6.10mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 15μin (0.38μm) |
| Color | Black |
