Technical Specifications of H3AWH-6036G
| Datasheet |  H3AWH-6036G datasheet |
|---|
| Product Photos | H3AWH-60 GPart Number Breakdown |
|---|
| Featured Product | Assmann - IDC Connectors and Cables |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Plug |
|---|
| Number of Positions | 60 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | Flange, Polarizing Key |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 15μin (0.38μm) |
|---|
| Online Catalog | Socket to Plug IDC Cable Assemblies |
|---|
| Assembly Component | (1) AE60G-300-ND - CBL RIBN 60COND 0.050 GRAY 300' (1) HSC60H-ND - CONN SOCKET IDC 60POS W/O KEY AU (1) HPL60H-ND - CONN PIN IDC 60POS W/ FLANGE |
|---|
| Alternate Color | H3AWH-6036M-ND - IDC CABLE - HSC60H/AE60M/HPL60H |
|---|
| Alternate Length | H3AWH-6006G-ND - IDC CABLE - HSC60H/AE60G/HPL60H H3AWH-6018G-ND - IDC CABLE - HSC60H/AE60G/HPL60H |
|---|
We can supply Assmann WSW Components part# H3AWH-6036G. Use the request quote form to request H3AWH-6036G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number H3AWH-6036G. The price and lead time for H3AWH-6036G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# H3AWH-6036G. We look forward to doing business with you.
