Technical Specifications of H2PXS-1406G
| Datasheet |  H2PXS-1406G datasheet |
|---|
| Product Photos | HxPXS-14 GPart Number Breakdown Assmann |
|---|
| Featured Product | Assmann - IDC Connectors and Cables |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | DIP to Cable |
|---|
| Number of Positions | 14 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 0.500' (152.40mm, 6.00") |
|---|
| Features | - |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | Socket (0.3"), Board In |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Tin |
|---|
| Contact Finish Thickness | - |
|---|
| Assembly Component | (1) AE14G-300-ND - CBL RIBN 14COND 0.050 GRAY 300' (1) HDP14S-ND - CONN DIP IDC 14POS TIN |
|---|
| Alternate Color | H2PXS-1406M-ND - DIP CABLE - HDP14S/AE14M/X |
|---|
| Alternate Length | H2PXS-1418G-ND - DIP CABLE - HDP14S/AE14G/X H2PXS-1436G-ND - DIP CABLE - HDP14S/AE14G/X |
|---|
We can supply Assmann WSW Components part# H2PXS-1406G. Use the request quote form to request H2PXS-1406G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number H2PXS-1406G. The price and lead time for H2PXS-1406G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# H2PXS-1406G. We look forward to doing business with you.
