Technical Specifications of M2MXH-2018J
| Datasheet |  M2MXH-2018J datasheet |
|---|
| Product Training Modules | Cable Matters |
|---|
| Featured Product | Ribbon Cable Assemblies |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | PCB to Cable |
|---|
| Number of Positions | 20 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 1.50' (457.20mm) |
|---|
| Features | - |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | Board In |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 15μin (0.38μm) |
|---|
| Online Catalog | Single Ended PCB Cable Assemblies |
|---|
| Assembly Component | (1) MC20G-300-ND - CBL RIBN 20COND 0.050 GRAY 300' (1) MDM20H-ND - CONN 20POS .1X.1 IDC RIBBON PCB |
|---|
| Alternate Color | M2MXH-2018R-ND - IDC CABLE - MDM20H/MC20M/X |
|---|
| Alternate Length | M2MXH-2006J-ND - IDC CABLE - MDM20H/MC20G/X M2MXH-2036J-ND - IDC CABLE - MDM20H/MC20G/X |
|---|
We can supply 3M part# M2MXH-2018J. Use the request quote form to request M2MXH-2018J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M2MXH-2018J. The price and lead time for M2MXH-2018J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M2MXH-2018J. We look forward to doing business with you.
