Technical Specifications of H3CCS-2006M
| Datasheet |  H3CCS-2006M datasheet |
|---|
| Product Photos | H3CCx-20 MPart Number Breakdown |
|---|
| Featured Product | Assmann - IDC Connectors and Cables |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Socket |
|---|
| Number of Positions | 20 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 0.500' (152.40mm, 6.00") |
|---|
| Features | Polarizing Key |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Tin |
|---|
| Contact Finish Thickness | - |
|---|
| Online Catalog | Socket to Socket IDC Cable Assemblies |
|---|
| Assembly Component | (1) AE20M-300-ND - CBL RIBN 20COND 0.050 MULTI 300' (2) HKC20S-ND - CONN SOCKET IDC 20POS W/KEY TIN |
|---|
| Alternate Color | H3CCS-2006G-ND - IDC CABLE - HKC20S/AE20G/HKC20S |
|---|
| Alternate Length | H3CCS-2018M-ND - IDC CABLE - HKC20S/AE20M/HKC20S H3CCS-2036M-ND - IDC CABLE - HKC20S/AE20M/HKC20S |
|---|
We can supply Assmann WSW Components part# H3CCS-2006M. Use the request quote form to request H3CCS-2006M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number H3CCS-2006M. The price and lead time for H3CCS-2006M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# H3CCS-2006M. We look forward to doing business with you.
