Technical Specifications of M1AXA-2036R
| Datasheet |  M1AXA-2036R datasheet |
|---|
| Product Photos | M1AXx-20 MPart Number Breakdown 3M 1or3 |
|---|
| Featured Product | Ribbon Cable Assemblies |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Cable |
|---|
| Number of Positions | 20 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | - |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Online Catalog | Single Ended Socket Cable Assemblies |
|---|
| Assembly Component | (1) MSC20A-ND - CONN 20 POS IDC SOCKET GOLD (1) MC20M-300-ND - CBL RIBN 20COND 0.050 MULTI 300' |
|---|
| Alternate Color | M1AXA-2036J-ND - IDC CABLE - MSC20A/MC20G/X |
|---|
| Other Names | M1AXG-2036R |
|---|
We can supply 3M part# M1AXA-2036R. Use the request quote form to request M1AXA-2036R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M1AXA-2036R. The price and lead time for M1AXA-2036R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M1AXA-2036R. We look forward to doing business with you.
