Technical Specifications of C3PES-5018M
| Datasheet |  C3PES-5018M datasheet |
|---|
| Product Photos | C3PES-50 M |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Card Edge to PCB |
|---|
| Number of Positions | 50 |
|---|
| Number of Rows | 2, 4 |
|---|
| Pitch - Connector | 0.050" (1.27mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 1.50' (457.20mm) |
|---|
| Features | - |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | Board In |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Tin |
|---|
| Contact Finish Thickness | 100μin (2.54μm) |
|---|
| Online Catalog | Card Edge to PCB Cable Assemblies |
|---|
| Assembly Component | (1) CPC50S-ND - CONN IDC 50PIN TIN PCB (1) CCE50S-ND - CONN CARDEDGE 50PIN TIN W/ORS (1) AE50M-300-ND - CBL RIBN 50COND 0.050 MULTI 300' |
|---|
| Alternate Color | C3PES-5018G-ND - IDC CABLE - CPC50S/AE50G/CCE50S |
|---|
| Alternate Length | C3PES-5006M-ND - IDC CABLE - CPC50S/AE50M/CCE50S C3PES-5036M-ND - IDC CABLE - CPC50S/AE50M/CCE50S |
|---|
We can supply CW Industries part# C3PES-5018M. Use the request quote form to request C3PES-5018M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C3PES-5018M. The price and lead time for C3PES-5018M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C3PES-5018M. We look forward to doing business with you.
