Technical Specifications of M3TKK-2036J
| Datasheet |  M3TKK-2036J datasheet |
|---|
| Product Photos | Part Number Breakdown 3M 1or3M3TKK-20 G |
|---|
| Product Training Modules | Cable Matters |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Plug |
|---|
| Number of Positions | 20 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | Polarizing Key |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Online Catalog | Socket to Plug Cable Assemblies |
|---|
| Assembly Component | (1) MSD20K-ND - SOCKET CONN 20 CONT CLOSED W/POL (1) MPK20K-ND - PLUG CONNECTOR 20 POS W/O FLANGE (1) MC20G-300-ND - CBL RIBN 20COND 0.050 GRAY 300' |
|---|
| Alternate Color | M3TKK-2036R-ND - IDC CABLE - MSD20K/MC20M/MPK20K |
|---|
| Alternate Length | M3TKK-2006J-ND - IDC CABLE - MSD20K/MC20G/MPK20K M3TKK-2018J-ND - IDC CABLE - MSD20K/MC20G/MPK20K |
|---|
We can supply 3M part# M3TKK-2036J. Use the request quote form to request M3TKK-2036J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M3TKK-2036J. The price and lead time for M3TKK-2036J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M3TKK-2036J. We look forward to doing business with you.
