Technical Specifications of C2RXS-1606G
| Datasheet |  C2RXS-1606G datasheet |
|---|
| Product Photos | CxRXS-16 GPart Number Breakdown CW |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | DIP to Cable |
|---|
| Number of Positions | 16 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 0.500' (152.40mm, 6.00") |
|---|
| Features | Strain Relief |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | Socket (0.3"), Board In |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Tin |
|---|
| Contact Finish Thickness | 100μin (2.54μm) |
|---|
| Online Catalog | Single Ended DIP Cable Assemblies |
|---|
| Assembly Component | (1) CDP16S-ND - CONNECTOR DIP 16 PIN TIN IDC (1) CDSR16-ND - STRAP STR RELIEF FOR DIP 16 CONN (1) AE16G-300-ND - CBL RIBN 16COND 0.050 GRAY 300' |
|---|
| Alternate Color | C2RXS-1606M-ND - DIP CABLE - CDR16S/AE16M/X |
|---|
| Alternate Length | C2RXS-1618G-ND - DIP CABLE - CDR16S/AE16G/X C2RXS-1636G-ND - DIP CABLE - CDR16S/AE16G/X |
|---|
We can supply CW Industries part# C2RXS-1606G. Use the request quote form to request C2RXS-1606G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C2RXS-1606G. The price and lead time for C2RXS-1606G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C2RXS-1606G. We look forward to doing business with you.
