Technical Specifications of H3WWH-4036M
| Datasheet |  H3WWH-4036M datasheet |
|---|
| Product Photos | H3WWH-40 MPart Number Breakdown |
|---|
| Featured Product | Assmann - IDC Connectors and Cables |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Plug to Plug |
|---|
| Number of Positions | 40 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | Flange, Polarizing Key |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 15μin (0.38μm) |
|---|
| Assembly Component | (1) AE40M-300-ND - CBL RIBN 40COND 0.050 MULTI 300' (2) HPL40H-ND - CONN PIN IDC 40POS W/ FLANGE |
|---|
| Alternate Color | H3WWH-4036G-ND - IDC CABLE - HPL40H/AE40G/HPL40H |
|---|
| Alternate Length | H3WWH-4006M-ND - IDC CABLE - HPL40H/AE40M/HPL40H H3WWH-4018M-ND - IDC CABLE - HPL40H/AE40M/HPL40H |
|---|
We can supply Assmann WSW Components part# H3WWH-4036M. Use the request quote form to request H3WWH-4036M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number H3WWH-4036M. The price and lead time for H3WWH-4036M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# H3WWH-4036M. We look forward to doing business with you.
