Technical Specifications of SMT-1220-TW-R
| Datasheet |  SMT-1220-TW-R datasheet |
|---|
| Product Photos | SMT-122X-TW-R |
|---|
| Catalog Drawings | SMT-122(0,4)-TR-R BottomSMT-122(0,4)-TR-R SideSMT-122(0,4)-TR-R Top |
|---|
| 3D Model | SMT-1220-TW-R.igs |
|---|
| Standard Package | 80 |
|---|
| Category | Audio Products |
|---|
| Family | Buzzers |
|---|
| Series | SMT |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Driver Circuitry | Transducer, Externally Driven |
|---|
| Technology | Magnetic |
|---|
| Input Type | peak-peak Signal |
|---|
| Voltage - Rated | 3Vp-p |
|---|
| Voltage Range | 2 ~ 5V |
|---|
| Frequency | 2kHz |
|---|
| Operating Mode | Continuous |
|---|
| Sound Pressure Level | 80dB @ 3V, 10cm |
|---|
| Current - Supply | 35mA |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Washable | Yes |
|---|
| Port Location | Top |
|---|
| Mounting Type | Surface Mount |
|---|
| Termination | Solder Pads |
|---|
| Size / Dimension | 12.0mm Dia x 9.3mm H |
|---|
| Capacitance @ Frequency | - |
|---|
| Online Catalog | SMT Series |
|---|
| Other Names | 668-1086 668-1086-1 668-1086-1-ND SMT1220TWR |
|---|
We can supply PUI Audio, Inc. part# SMT-1220-TW-R. Use the request quote form to request SMT-1220-TW-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SMT-1220-TW-R. The price and lead time for SMT-1220-TW-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SMT-1220-TW-R. We look forward to doing business with you.
