| Datasheet |  AN-1305 datasheet |
|---|
| Product Photos | AN-1305 |
|---|
| Product Training Modules | Avoiding the Top 5 Pitfalls of NEMA EnclosuresModified Enclosures |
|---|
| Video File | Bud's Custom CapabilitiesCustom BUD Box Enclosures – Another Geek Moment |
|---|
| Featured Product | Customize Your EnclosureAN-Series Waterproof Enclosures |
|---|
| 2D Drawing | AN-1305(-G), AN-2805(-B).dxf |
|---|
| Standard Package | 1 |
|---|
| Category | Boxes, Enclosures, Racks |
|---|
| Family | Boxes |
|---|
| Series | AN |
|---|
| Container Type | Box |
|---|
| Size / Dimension | 5.830" L x 4.252" W (148.08mm x 108.00mm) |
|---|
| Height | 2.950" (74.93mm) |
|---|
| Area (L x W) | 24.8" (160cm) |
|---|
| Design | Cover Included |
|---|
| Material | Metal, Aluminum |
|---|
| Color | Natural |
|---|
| Thickness | 0.130" (3.30mm) |
|---|
| Features | Card Guides, PCB Supports, Watertight |
|---|
| Ratings | IP65, IP66, NEMA 1,2,4,4X,12,13, UL-508 |
|---|
| Material Flammability Rating | - |
|---|
| Shipping Info | Shipped from Digi-Key |
|---|
| Weight | 1.5 lbs (680.4g) |
|---|
| Associated Product | 377-1606-ND - KIT WALL MOUNTING BRACKET NAT ANX-91305-ND - PANEL ALUM 5.37X3.79X0.06" |
|---|
| Alternate Color | 377-1193-ND - BOX ALUM GRAY 5.83"L X 4.25"W |
|---|
| Other Names | 377-1104 AN 1305 AN1305 |
|---|
