| Datasheet |  AN-2817 datasheet |
|---|
| Product Photos | AN-2817 |
|---|
| Product Training Modules | Avoiding the Top 5 Pitfalls of NEMA EnclosuresModified Enclosures |
|---|
| Video File | Bud's Custom CapabilitiesCustom BUD Box Enclosures – Another Geek Moment |
|---|
| Catalog Drawings | AN-28, CN-67 Series |
|---|
| Featured Product | Customize Your EnclosureAN-Series Waterproof Enclosures |
|---|
| 2D Drawing | AN-1317(-G), AN-2817(-B).dxf |
|---|
| Standard Package | 1 |
|---|
| Category | Boxes, Enclosures, Racks |
|---|
| Family | Boxes |
|---|
| Series | AN |
|---|
| Container Type | Box with Mounting Flange |
|---|
| Size / Dimension | 6.290" L x 3.930" W (159.77mm x 99.82mm) |
|---|
| Height | 3.190" (81.03mm) |
|---|
| Area (L x W) | 24.7" (159cm) |
|---|
| Design | Cover Included |
|---|
| Material | Metal, Aluminum |
|---|
| Color | Natural |
|---|
| Thickness | 0.120" (3.05mm) |
|---|
| Features | PCB Supports, Watertight |
|---|
| Ratings | IP65, IP66, NEMA 1,2,4,4X,12,13, UL-508 |
|---|
| Material Flammability Rating | - |
|---|
| Shipping Info | Shipped from Digi-Key |
|---|
| Weight | 2.1 lbs (952.5g) |
|---|
| Associated Product | 377-1606-ND - KIT WALL MOUNTING BRACKET NAT 377-1607-ND - KIT WALL MOUNTING BRACKET BLACK 377-1608-ND - KIT WALL MOUNTING BRACKET GRAY ANX-91316-ND - PANEL ALUM 5.79X3.43X0.06" |
|---|
| Alternate Color | 377-1461-ND - BOX ALUM BLACK 6.29"L X 3.93"W |
|---|
| Other Names | 377-1460 AN 2817 AN2817 |
|---|
