Technical Specifications of A9CCA-1504F
| Datasheet |  A9CCA-1504F datasheet |
|---|
| Product Photos | A9CCx-150xx |
|---|
| Catalog Drawings | A9CCA Assembly Pin Out |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Flat Flex Cables (FFC, FPC) |
|---|
| Series | - |
|---|
| Contact Termination | Receptacle with Latch to Receptacle with Latch |
|---|
| Length | 4.0" (101.6mm) |
|---|
| Number of Positions | 15 |
|---|
| Pitch | 0.100" (2.54mm) |
|---|
| Online Catalog | Flex Cable |
|---|
| Assembly Component | (30) 2-487406-3-ND - CONN SOCKET FLEXFLAT .100 30GOLD (2) 1-487526-4-ND - CONN FFC RCPT HSG 15POS 2.54MM (1) AF15-500-ND - CABLE FLAT FLEX 15COND 0.100" |
|---|
| Alternate Length | A9CCA-1502F-ND - FLEX CABLE - AFG15A/AF15/AFG15A A9CCA-1503F-ND - FLEX CABLE - AFG15A/AF15/AFG15A A9CCA-1505F-ND - FLEX CABLE - AFG15A/AF15/AFG15A A9CCA-1506F-ND - FLEX CABLE - AFG15A/AF15/AFG15A A9CCA-1508F-ND - FLEX CABLE - AFG15A/AF15/AFG15A |
|---|
We can supply TE Connectivity AMP Connectors part# A9CCA-1504F. Use the request quote form to request A9CCA-1504F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number A9CCA-1504F. The price and lead time for A9CCA-1504F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# A9CCA-1504F. We look forward to doing business with you.
