Technical Specifications of A9BAA-0803F
| Datasheet |  A9BAA-0803F datasheet |
|---|
| Product Photos | A9BAx-080xx |
|---|
| Catalog Drawings | A9BAA Assembly Pin Out |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Flat Flex Cables (FFC, FPC) |
|---|
| Series | - |
|---|
| Contact Termination | Receptacle to Solder Tab |
|---|
| Length | 3.0" (76.2mm) |
|---|
| Number of Positions | 8 |
|---|
| Pitch | 0.100" (2.54mm) |
|---|
| Online Catalog | Flex Cable |
|---|
| Assembly Component | (1) 487378-7-ND - CONN FFC RCPT HSG 8POS 2.54MM (8) 1-88997-2-ND - CONN CONTACT SLDR TAB FLAT FLEX (8) 2-487406-3-ND - CONN SOCKET FLEXFLAT .100 30GOLD (1) AF08-500-ND - CABLE FLAT FLEX 8COND 0.100" |
|---|
| Alternate Length | A9BAA-0802F-ND - FLEX CABLE - AFF08A/AF08/AFE08T A9BAA-0804F-ND - FLEX CABLE - AFF08A/AF08/AFE08T A9BAA-0805F-ND - FLEX CABLE - AFF08A/AF08/AFE08T A9BAA-0806F-ND - FLEX CABLE - AFF08A/AF08/AFE08T A9BAA-0808F-ND - FLEX CABLE - AFF08A/AF08/AFE08T |
|---|
We can supply TE Connectivity AMP Connectors part# A9BAA-0803F. Use the request quote form to request A9BAA-0803F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number A9BAA-0803F. The price and lead time for A9BAA-0803F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# A9BAA-0803F. We look forward to doing business with you.
