Technical Specifications of H3DKH-2636G
| Datasheet |  H3DKH-2636G datasheet |
|---|
| Product Photos | H3DKH-26 GPart Number Breakdown |
|---|
| Featured Product | Assmann - IDC Connectors and Cables |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Plug |
|---|
| Number of Positions | 26 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | Polarizing Key, Strain Relief (Socket); Polarizing Key (Plug) |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 15μin (0.38μm) |
|---|
| Online Catalog | Socket to Plug IDC Cable Assemblies |
|---|
| Assembly Component | (1) AE26G-300-ND - CBL RIBN 26COND 0.050 GRAY 300' (1) HKR26H-ND - CONN SOCKET IDC 26POS W/STR GOLD |
|---|
| Alternate Color | H3DKH-2636M-ND - IDC CABLE - HKR26H/AE26M/HPK26H |
|---|
| Alternate Length | H3DKH-2606G-ND - IDC CABLE - HKR26H/AE26G/HPK26H H3DKH-2618G-ND - IDC CABLE - HKR26H/AE26G/HPK26H |
|---|
We can supply Assmann WSW Components part# H3DKH-2636G. Use the request quote form to request H3DKH-2636G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number H3DKH-2636G. The price and lead time for H3DKH-2636G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# H3DKH-2636G. We look forward to doing business with you.
