Technical Specifications of PSR1636-25
| Datasheet |  PSR1636-25 datasheet |
|---|
| Product Photos | PS-1636-25 |
|---|
| Catalog Drawings | PSR1636 Series |
|---|
| Standard Package | 1 |
|---|
| Category | Cables, Wires |
|---|
| Family | Flat Flex Cables (FFC, FPC) |
|---|
| Series | PSR1636 |
|---|
| Number of Conductors | 25 |
|---|
| Pitch | 0.050" (1.27mm) |
|---|
| Cable Length | 500' (152.4m) |
|---|
| Cable Width | 1.30" (33.02mm) |
|---|
| Jacket (Insulation) Material | Polyester |
|---|
| Jacket (Insulation) Thickness | 0.0020" (0.051mm) |
|---|
| Conductor Material | Copper, Bare |
|---|
| Conductor Plating | Tin |
|---|
| Ratings | UL Style 2643 |
|---|
| Features | Conductor 1 Tinned |
|---|
| Current Rating | 2.5A |
|---|
| Voltage Rating | 300V |
|---|
| Operating Temperature | 105°C |
|---|
| Wire Gauge | 30 AWG (Equivalent) |
|---|
| Conductor Thickness | 0.003" (0.08mm) |
|---|
| Assembly | A9AAT-2502E-ND - FLEX CABLE - AFH25T/AE25/AFH25T A9AAT-2503E-ND - FLEX CABLE - AFH25T/AE25/AFH25T A9AAT-2504E-ND - FLEX CABLE - AFH25T/AE25/AFH25T A9AAT-2505E-ND - FLEX CABLE - AFH25T/AE25/AFH25T A9AAT-2506E-ND - FLEX CABLE - AFH25T/AE25/AFH25T A9AAT-2508E-ND - FLEX CABLE - AFH25T/AE25/AFH25T A9BAA-2502E-ND - FLEX CABLE - AFJ25A/AE25/AFH25T A9BAA-2503E-ND - FLEX CABLE - AFJ25A/AE25/AFH25T A9BAA-2504E-ND - FLEX CABLE - AFJ25A/AE25/AFH25T A9BAA-2505E-ND - FLEX CABLE - AFJ25A/AE25/AFH25T A9BAA-2506E-ND - FLEX CABLE - AFJ25A/AE25/AFH25T A9BAA-2508E-ND - FLEX CABLE - AFJ25A/AE25/AFH25T A9CAA-2502E-ND - FLEX CABLE - AFK25A/AE25/AFH25T A9CAA-2503E-ND - FLEX CABLE - AFK25A/AE25/AFH25T A9CAA-2504E-ND - FLEX CABLE - AFK25A/AE25/AFH25T A9CAA-2505E-ND - FLEX CABLE - AFK25A/AE25/AFH25T A9CAA-2506E-ND - FLEX CABLE - AFK25A/AE25/AFH25T A9CAA-2508E-ND - FLEX CABLE - AFK25A/AE25/AFH25T A9BBA-2502E-ND - FLEX CABLE - AFJ25A/AE25/AFJ25A A9BBA-2503E-ND - FLEX CABLE - AFJ25A/AE25/AFJ25A A9BBA-2504E-ND - FLEX CABLE - AFJ25A/AE25/AFJ25A A9BBA-2505E-ND - FLEX CABLE - AFJ25A/AE25/AFJ25A A9BBA-2506E-ND - FLEX CABLE - AFJ25A/AE25/AFJ25A A9BBA-2508E-ND - FLEX CABLE - AFJ25A/AE25/AFJ25A A9CCA-2502E-ND - FLEX CABLE - AFK25A/AE25/AFK25A A9CCA-2503E-ND - FLEX CABLE - AFK25A/AE25/AFK25A A9CCA-2504E-ND - FLEX CABLE - AFK25A/AE25/AFK25A A9CCA-2505E-ND - FLEX CABLE - AFK25A/AE25/AFK25A A9CCA-2506E-ND - FLEX CABLE - AFK25A/AE25/AFK25A A9CCA-2508E-ND - FLEX CABLE - AFK25A/AE25/AFK25A |
|---|
| Other Names | AE25-500 PS-1636-25 PSR163625 |
|---|
We can supply Parlex USA LLC part# PSR1636-25. Use the request quote form to request PSR1636-25 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PSR1636-25. The price and lead time for PSR1636-25 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PSR1636-25. We look forward to doing business with you.
