Technical Specifications of EET-UQ2S561KF
| Product Photos | EET-UQ2S561KF |
|---|
| Catalog Drawings | TS Series 4mm Pin LengthTS Series bottom_30TS Series side_45 |
|---|
| PCN Obsolescence/ EOL | UQ Series 03/Jul/2013 |
|---|
| PCN Design/Specification | Form, Labeling, Material 07/May/2013 |
|---|
| PCN Other | Snap-In Al electrolytic REACH 07/May/2013 |
|---|
| Standard Package | 100 |
|---|
| Category | Capacitors |
|---|
| Family | Aluminum Capacitors |
|---|
| Series | TS-UQ |
|---|
| Packaging | Bulk |
|---|
| Capacitance | 560μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage Rating | 420V |
|---|
| ESR (Equivalent Series Resistance) | 355 mOhm @ 120Hz |
|---|
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
|---|
| Operating Temperature | -25°C ~ 85°C |
|---|
| Polarization | Polar |
|---|
| Applications | General Purpose |
|---|
| Ripple Current | 2.82A @ 120Hz |
|---|
| Impedance | - |
|---|
| Lead Spacing | 0.394" (10.00mm) |
|---|
| Size / Dimension | 1.181" Dia (30.00mm) |
|---|
| Height - Seated (Max) | 1.772" (45.00mm) |
|---|
| Surface Mount Land Size | - |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial, Can - Snap-In |
|---|
| Other Names | EETUQ2S561KF P13905 |
|---|
We can supply Panasonic Electronic Components part# EET-UQ2S561KF. Use the request quote form to request EET-UQ2S561KF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number EET-UQ2S561KF. The price and lead time for EET-UQ2S561KF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# EET-UQ2S561KF. We look forward to doing business with you.
