Technical Specifications of ECO-S1CP682BA
| Product Photos | TS-UP22 SERIES(25.00mm) |
|---|
| Product Training Modules | LED Lighting Components |
|---|
| Catalog Drawings | TS Series side_25 |
|---|
| PCN Obsolescence/ EOL | ECO-S,EET,ECE-C,ECE-T,ECE-3 Series 16/Jun/2014 |
|---|
| PCN Design/Specification | Form, Labeling, Material 07/May/2013 |
|---|
| PCN Other | Snap-In Al electrolytic REACH 07/May/2013 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 200 |
|---|
| Category | Capacitors |
|---|
| Family | Aluminum Capacitors |
|---|
| Series | TS-UP |
|---|
| Packaging | Bulk |
|---|
| Capacitance | 6800μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage Rating | 16V |
|---|
| ESR (Equivalent Series Resistance) | 110 mOhm @ 120Hz |
|---|
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Polarization | Polar |
|---|
| Applications | General Purpose |
|---|
| Ripple Current | 2.57A @ 120Hz |
|---|
| Impedance | - |
|---|
| Lead Spacing | 0.394" (10.00mm) |
|---|
| Size / Dimension | 0.866" Dia (22.00mm) |
|---|
| Height - Seated (Max) | 1.063" (27.00mm) |
|---|
| Surface Mount Land Size | - |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial, Can - Snap-In |
|---|
| Other Names | ECOS1CP682BA P7346 P7346-ND P7601 |
|---|
We can supply Panasonic Electronic Components part# ECO-S1CP682BA. Use the request quote form to request ECO-S1CP682BA pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ECO-S1CP682BA. The price and lead time for ECO-S1CP682BA depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ECO-S1CP682BA. We look forward to doing business with you.
