Technical Specifications of C3225X7R1E106M250AC
| Datasheet |  C3225X7R1E106M250AC datasheet |
|---|
| Product Photos | C Series 1210(3225 Metric) 28 |
|---|
| Product Training Modules | High Capacitance ReplacementC Series General ApplicationsSEAT, CCV, and TVCL Design ToolsGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Catalog Drawings | C SERIES_1210_2.8 |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | C |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 10μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage - Rated | 25V |
|---|
| Temperature Coefficient | X7R |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Applications | General Purpose |
|---|
| Ratings | - |
|---|
| Package / Case | 1210 (3225 Metric) |
|---|
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.106" (2.70mm) |
|---|
| Lead Spacing | - |
|---|
| Features | Low ESL |
|---|
| Lead Style | - |
|---|
| Online Catalog | C Series, General Purpose |
|---|
| Other Names | 445-1434-2 C3225X7R1E106M C3225X7R1E106MT C3225X7R1E106MTJ00N |
|---|
We can supply TDK Corporation part# C3225X7R1E106M250AC. Use the request quote form to request C3225X7R1E106M250AC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C3225X7R1E106M250AC. The price and lead time for C3225X7R1E106M250AC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C3225X7R1E106M250AC. We look forward to doing business with you.
