| Datasheet |  CGA9N4X7R2J224K230KA datasheet |
|---|
| Product Photos | CGA Series 2220 (5750 Metric) 2.3 |
|---|
| Product Training Modules | CGA Series for Automotive ApplicationsSEAT, CCV, and TVCL Design ToolsGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Featured Product | CGA Series MLCC Capacitors |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 500 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | CGA |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 0.22μF |
|---|
| Tolerance | ±10% |
|---|
| Voltage - Rated | 630V |
|---|
| Temperature Coefficient | X7R |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Applications | Automotive |
|---|
| Ratings | AEC-Q200 |
|---|
| Package / Case | 2220 (5750 Metric) |
|---|
| Size / Dimension | 0.224" L x 0.197" W (5.70mm x 5.00mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.091" (2.30mm) |
|---|
| Lead Spacing | - |
|---|
| Features | - |
|---|
| Lead Style | - |
|---|
| Online Catalog | CGA Series, Automotive General, Mid and High Voltage |
|---|
| Other Names | 445-7946-2 CGA9N4X7R2J224K CGA9N4X7R2J224KT0Y0U |
|---|
