| Datasheet |  CGA3E2X8R1H103K080AD datasheet |
|---|
| Product Photos | CGA Epoxy Series 0603 (1608 Metric) |
|---|
| Mfg Application Notes | MLCC Conductive Epoxy FAQs |
|---|
| Product Training Modules | CGA Series for Automotive ApplicationsSEAT, CCV, and TVCL Design ToolsC Series High Temp Capacitor FamilyC Series Conductive Epoxy Capacitor FamilyGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Featured Product | CGA Series MLCC CapacitorsC Series High Temperature X8R MLCCC Series Conductive Epoxy MLCC |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 4,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | CGA |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 10000pF |
|---|
| Tolerance | ±10% |
|---|
| Voltage - Rated | 50V |
|---|
| Temperature Coefficient | X8R |
|---|
| Mounting Type | Surface Mount, MLCC, Epoxy |
|---|
| Operating Temperature | -55°C ~ 150°C |
|---|
| Applications | Automotive |
|---|
| Ratings | AEC-Q200 |
|---|
| Package / Case | 0603 (1608 Metric) |
|---|
| Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.035" (0.90mm) |
|---|
| Lead Spacing | - |
|---|
| Features | Epoxy Mountable |
|---|
| Lead Style | - |
|---|
| Online Catalog | CGA Series, Epoxy Mounted |
|---|
| Other Names | 445-8823-2 C1608X8R1H103K/EPOXY CGA3E2X8R1H103KT0Y0B |
|---|
