Technical Specifications of ECH-U1C121GX5
| Datasheet |  ECH-U1C121GX5 datasheet |
|---|
| Product Photos | ECH-UX Series 0603 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 4,000 |
|---|
| Category | Capacitors |
|---|
| Family | Film Capacitors |
|---|
| Series | ECH-U(X) |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 120pF |
|---|
| Tolerance | ±2% |
|---|
| Voltage Rating - AC | - |
|---|
| Voltage Rating - DC | 16V |
|---|
| Dielectric Material | Polyphenylene Sulfide (PPS), Metallized - Stacked |
|---|
| ESR (Equivalent Series Resistance) | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 0603 (1608 Metric) |
|---|
| Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) |
|---|
| Height - Seated (Max) | 0.033" (0.85mm) |
|---|
| Termination | Solder Pads |
|---|
| Lead Spacing | - |
|---|
| Applications | General Purpose |
|---|
| Features | Derating Recommended |
|---|
| Online Catalog | ECH-U(X) Series |
|---|
| Other Names | ECHU1C121GX5 PCF1442TR |
|---|
We can supply Panasonic Electronic Components part# ECH-U1C121GX5. Use the request quote form to request ECH-U1C121GX5 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ECH-U1C121GX5. The price and lead time for ECH-U1C121GX5 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ECH-U1C121GX5. We look forward to doing business with you.
