Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MF-SM100-2-99 |
|---|---|
| Manufacturer | Bourns Inc. |
| Description | FUSE RESETTABLE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MF-SM100-2-99 Price |  |
Technical Specifications of MF-SM100-2-99
| Datasheet |  MF-SM100-2-99 datasheet |
|---|---|
| Product Photos | MF-SM150MF-SM030 thru 125, 260, 300 |
| Product Training Modules | Multifuse® Resettable fusesESD Protection Products |
| RoHS Information | MF-SM Series Material Declaration |
| Catalog Drawings | MF-SM Series FootprintMF-SM030,050,075,100,100^33,125,260,300 EndMF-SM100,100^33,125,260,300 Side |
| 3D Model | MF-SM100-2.stp |
| PCN Design/Specification | MF-SM(250), SMHT Series Cover Tape Nov/2010MF Cert Mark Aug/2015 |
| Standard Package | 2,000 |
| Category | Circuit Protection |
| Family | PTC Resettable Fuses |
| Series | MF-SM |
| Packaging | Tape & Reel (TR) |
| Voltage - Max | 30V |
| Current - Max | 80A |
| Current - Hold (Ih) (Max) | 1.1A |
| Current - Trip (It) | 2.2A |
| R Min/Max | 0.120 ~ 0.480 Ohm |
| Time to Trip | 0.5s |
| Package / Case | 2-SMD |
| Online Catalog | MF-SM Series |
| Other Names | MF-SM100-2-99-ND MF-SM100-2-99TR MFSM100299 |
