Technical Specifications of MASMCJ70A
| Datasheet |  MASMCJ70A datasheet |
|---|
| Product Photos | DO-214AB |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | Military, MIL-PRF-19500 |
|---|
| Packaging | Bulk |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 1 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 70V |
|---|
| Voltage - Breakdown (Min) | 77.8V |
|---|
| Voltage - Clamping (Max) @ Ipp | 113V |
|---|
| Current - Peak Pulse (10/1000μs) | 13.3A |
|---|
| Power - Peak Pulse | 1500W (1.5kW) |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -65°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | DO-214AB, SMC |
|---|
| Supplier Device Package | DO-214AB (SMCJ) |
|---|
| Other Names | 1086-6082 |
|---|
We can supply Microsemi HI-REL [MIL] part# MASMCJ70A. Use the request quote form to request MASMCJ70A pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MASMCJ70A. The price and lead time for MASMCJ70A depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MASMCJ70A. We look forward to doing business with you.
