Technical Specifications of SESD0402X1BN-0015-096
| Datasheet |  SESD0402X1BN-0015-096 datasheet |
|---|
| Product Photos | 0402 |
|---|
| Featured Product | Silicon ESD Protection Devices SESD Series |
|---|
| Standard Package | 10,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | SESD, SPA? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 1 |
|---|
| Voltage - Reverse Standoff (Typ) | 7V (Max) |
|---|
| Voltage - Breakdown (Min) | 9.6V (Typ) |
|---|
| Voltage - Clamping (Max) @ Ipp | 14V (Typ) |
|---|
| Current - Peak Pulse (10/1000μs) | 2.5A (8/20μs) |
|---|
| Power - Peak Pulse | - |
|---|
| Power Line Protection | No |
|---|
| Applications | HDMI |
|---|
| Capacitance @ Frequency | 0.15pF @ 3GHz |
|---|
| Operating Temperature | -55°C ~ 125°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2-XDFN |
|---|
| Supplier Device Package | 0402 |
|---|
| Online Catalog | SPA? SESD Series |
|---|
| Other Names | F6722TR RF3922-000 RF3922000 SESD0402X1BN-0015096 SESD0402X1BN0015-096 SESD0402X1BN0015096 |
|---|
We can supply Littelfuse Inc. part# SESD0402X1BN-0015-096. Use the request quote form to request SESD0402X1BN-0015-096 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SESD0402X1BN-0015-096. The price and lead time for SESD0402X1BN-0015-096 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SESD0402X1BN-0015-096. We look forward to doing business with you.
