Technical Specifications of SMDA24C-7.TBT
| Datasheet |  SMDA24C-7.TBT datasheet |
|---|
| Product Photos | 8-SOIC |
|---|
| PCN Design/Specification | Lead Frame Update 20/Apr/2015 |
|---|
| Standard Package | 500 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | SMDAC-7 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 7 |
|---|
| Voltage - Reverse Standoff (Typ) | 24V (Max) |
|---|
| Voltage - Breakdown (Min) | 26.7V |
|---|
| Voltage - Clamping (Max) @ Ipp | 43V |
|---|
| Current - Peak Pulse (10/1000μs) | 5A (8/20μs) |
|---|
| Power - Peak Pulse | 300W |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | 50pF @ 1MHz |
|---|
| Operating Temperature | -55°C ~ 125°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
|---|
| Supplier Device Package | 8-SO |
|---|
| Online Catalog | SMDAxxC-7 Series |
|---|
| Other Names | SMDA24C-7.TBTTR |
|---|
We can supply Semtech Corporation part# SMDA24C-7.TBT. Use the request quote form to request SMDA24C-7.TBT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SMDA24C-7.TBT. The price and lead time for SMDA24C-7.TBT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SMDA24C-7.TBT. We look forward to doing business with you.
